WHAT IS A PERIPHERAL PUMP NEEDED?
A close-coupled centrifugal pump known as a peripheral pump features an impeller with several radial vanes on the exterior edge. Large amounts of energy are transferred while the impeller rotates inside the casing's concentric channel while liquid flows between the vanes and casing, increasing the pressure inside the pump. Fluid flows from the casing's input to its outlet when the pressure inside it rises.
| Specification | Details |
|---|---|
| Power Supply | (Single Phase) 230 V ±10% @ 50 Hz |
| Motor Output | 0.37 KW (0.5 HP) |
| Load Speed | 2 850 RPM |
| Flow Rate | 40 L/PM |
| Max Pressure | 10 Bar (146 PSI) |
| Gauge Increments | 0.2 Bar |
| Pump Height | 0-33 H/M |
| Amperage | 2.6 A |
| Max. Liquid Temperature | +90° C |
| Protection Degree | IP44 |
| Gauge Measurement | Bar |
| Pump Amperage | 2.6 A |
| Max Ambient Temperature | +40° C |
| Starting Pressure Range | 4 - 8 Bar (58-117 PSI) |
| Power Output | 0.37 KW (0.5 HP) |
