Introducing the Deye 60kW On-Grid Inverter: Empower Your Solar Energy Solutions
Unlock the full potential of your solar panels with the Deye 60kW On-Grid Inverter. Designed for both efficiency and versatility, this inverter seamlessly integrates into your solar power system, providing reliable energy solutions for residential and commercial use.
Specifications
| Feature | Details |
|---|---|
| Model | SUN-60K-G |
| Rated Output Power | 60 kW |
| Input Power | 78 kW |
| Input Voltage | 1000 V |
| Startup Voltage | 250 V |
| MPPT Voltage Range | 200-850 V |
| Rated PV Input Voltage | 600 V |
| Input Short Circuit Current | 60 A (max) |
| Operating PV Input Current | 40 A (typical) |
| Number of MPP Trackers | 4 |
| Number of Strings per MPP Tracker | 3 (3+3+3+3) |
| Rated AC Output Active Power | 60 kW |
| Max. AC Output Apparent Power | 66 kVA |
| Rated AC Output Current | 90.9 A (typical) |
| Max. AC Output Current | 100 A (max) |
| Rated Output Voltage/Range | 220/380V, 230/400V 0.85Un-1.1Un |
| Rated Grid Frequency/Range | 50Hz/45Hz-55Hz, 60Hz/55Hz-65Hz |
| Power Factor Adjustment Range | 0.8 leading to 0.8 lagging |
| Total Harmonic Distortion (THDi) | <3% |
| Max. Efficiency | 98.7% |
| Euro Efficiency | 98.3% |
| Noise Emission (Typical) | ≤50 dB |
| Dimensions (WxHxD mm) | 700×575×297 |
| Weight | 60 kg |
| Cooling Concept | Intelligent Air Cooling |
| Ingress Protection | IP65 |
| Operating Temperature | -25 to 65℃ (Derating > 45℃) |
| Warranty | 5 Years |
| Surge Protection | Yes |
| DC Injection Current | 45 |
| DC Reverse-Polarity Protection | Yes |
| AC Short Circuit Protection | Yes |
| AC Output Overcurrent Protection | Yes |
| Output Overvoltage Protection | Yes |
| Insulation Resistance Protection | Yes |
| Ground Fault Monitoring | Yes |
| Anti-Islanding Protection | Yes |
| Temperature Protection | Yes |
| Integrated DC Switch | Yes |
| Remote Software Upload | Yes |
| Remote Change of Operating Parameters | Yes |
| Display Interface | LCD 240 × 160 |
| Communication Ports | RS485/RS232/Wifi/LAN |
Key Features
-
Solar Power Integration: The Deye 60kW On-Grid Inverter allows for effective installation of photovoltaic panels, maximizing your investment in solar energy.
-
Versatile Applications: Ideal for solar power installations in both commercial and residential settings, this inverter accommodates a variety of solar panel systems for homes.
-
Mobile/Portable Options: Enjoy the flexibility of powered by solar solutions with a mobile or portable battery inverter unit, perfect for events and emergency backup.
Safety and Installation Guidelines
-
Professional Installation: Ensure your Deye inverter is installed by certified professionals to guarantee safety and optimal performance. This is essential for solar panels installation.
-
Ventilation: Maintain a well-ventilated installation area to prevent overheating and ensure efficient operation of your solar energy system for home.
-
Follow Manufacturer Guidelines: Adhere strictly to the manufacturer’s instructions for installation and maintenance, ensuring secure operation of your solar power solar system.
-
No Unauthorized Modifications: Avoid making any changes to the inverter or battery unit that could compromise safety and efficiency.
General Applications
The Deye 60kW inverter is perfect for:
- Large-scale solar power installations in commercial and industrial environments, ensuring reliable integration with the grid.
- Homeowners seeking to maximize their solar panels for your home, significantly reducing electricity costs.
- Providing backup power for outdoor activities and emergencies.
Enhance Your Solar System
Complement your Deye 60kW On-Grid Inverter with our range of solar solutions and accessories. Explore solar suppliers and take advantage of combo deals that offer significant savings and extended warranty benefits for your solar installation.
Conclusion
Invest in the Deye 60kW On-Grid Inverter to enhance your energy solutions with a powerful, flexible, and efficient system tailored for your needs. Whether you're exploring the price of solar panels in South Africa or integrating a home solar system, the Deye inverter is your trusted partner in achieving sustainable energy independence.
With the Deye 60kW inverter, you’re not just investing in a product; you’re embracing a greener future powered by solar energy. Make the transition today and enjoy the benefits of renewable energy!
Download DEYE 60KW On Grid - Manual
Download DEYE 60KW On Grid - Datasheet
