Deye 12KW Hybrid Inverter - Advanced Solar Power Solution
The Deye 12KW Hybrid Inverter with advanced Battery Management System (BMS) technology is designed to provide unparalleled safety, stability, and efficiency in hybrid power systems. Perfect for residential and commercial solar installations, this inverter ensures seamless integration and reliable power management.
Cutting-Edge Features
- Incorporates a 48V low voltage battery with transformer isolation design.
- Supports 6 programmable time periods for efficient battery charging/discharging.
- Handles a maximum charging/discharging current of 240A.
- Employs frequency droop control and supports up to 16 units in parallel.
- Allows DC and AC coupling for seamless integration with existing solar systems.
- Capable of storing energy from diesel generators and offers three-phase unbalanced output.
- Features unique Smart Load application and Grid peak-shaving function for optimized performance.
- Provides 100% Unbalanced Output capability across phases.
Innovative Technologies
- Implements frequency droop control technology for enhanced reliability and stability.
- Adjusts output power by modulating frequency and voltage akin to traditional diesel generators.
- Supports a maximum of 16 units in parallel configuration.
Optimized Efficiency
- Enhances self-consumption ratio by up to 80%, leading to substantial electricity bill reductions.
- Supports a DC/AC ratio up to 1.3, perfectly suited for double-side PV modular setups.
- Features dual MPPT designs with a maximum efficiency of 97.6%.
User-Friendly Design
- Equipped with an intuitive LCD touchscreen and user-friendly button interface for effortless operation.
- Compatible with both lithium-ion and lead-acid batteries.
- Supports web browser and mobile App monitoring for convenient remote management.
Robust Protection and Operational Features
- Includes comprehensive protections such as PV lighting, anti-islanding, and leakage current protection.
- Ensures continuous operation by storing energy from diesel generators, guaranteeing 24/7 functionality.
- Boasts IP65 protection rating for durability in both indoor and outdoor environments.
- Swiftly transitions from on-grid to off-grid mode within 5ms, with a rapid zero exporting function responding in just 200ms.
GRID/AC OUTPUT Specifications
- Configured for Three-Phase grid output with IP65 protection.
- Handles a maximum charge/discharge current of 240A and adapts lithium-ion battery charging strategies through BMS.
- Offers AC Output & UPS Power of 12000W with a peak AC output power of 13200W.
- Provides an AC output rated current of 18.2/17.4A and maximum AC current of 27.3/26.1A.
- Achieves a maximum efficiency rating of 97.60%.
PV INPUT Details
- Supports a maximum DC input power of 15600W and operates at a rated PV input voltage of 550V (160-800V).
- Features 2 x MPPT trackers with a start-up voltage of 160V and PV input current handling capabilities of 26A + 13A.
Battery Compatibility
- Compatible with both Lead-acid and Lithium-ion batteries (sold separately), communicating seamlessly with BMS via CAN/RS485 interfaces.
Dimensions and Warranty
- Weighs 33.6 kg with dimensions measuring 422 x 699 x 279 mm.
- Covered by a reassuring 5-year warranty.
Specifications Table
| Feature | Specification |
|---|---|
| Rated Power | 12000W |
| DC Input | 48VDC, 240A |
| AC Output | 230VAC, 50/60Hz, 18.2/17.4A |
| Output Voltage Waveform | Pure Sine Wave |
| Output Voltage Regulation | 230Vac ±5% |
| Output Frequency | 60Hz or 50Hz |
| Peak Efficiency | 97.6% |
| Overload Protection | 100ms @ ≥205% load, 5s @ ≥150% load, 10s @ 110-150% load |
| Surge Capacity | 2x rated power for 5 seconds |
| Max. PV Array Power | 15600W |
| Max. PV Array Open Circuit Voltage | 500VDC |
| PV Array MPPT Voltage Range | 160VDC - 800VDC |
| Startup Voltage (Voc) | 160VDC |
| Max. Input Current | 26A + 13A |
| Battery Compatibility | Lead-acid, Lithium-ion |
| Communication with BMS | CAN/RS485 |
| Dimensions (W x H x D) | 422 x 699 x 279 mm |
| Weight | 33.6 kg |
| Warranty | 5 Years |
Download Links
Ensure a reliable and efficient solar power system with the Deye 12KW Hybrid Inverter. Invest in advanced solar technology and enjoy significant energy savings and stability.
For further inquiries, visit our website or contact us directly to learn more about how the Deye 12KW Hybrid Inverter can revolutionize your solar power system.
